Transmission Pan Interior

Jim Jennings Transmissions performs hundreds of transmission maintenance procedures every year. These photos show what we find when we remove the transmission's sump pan during a service.The amount of debris helps us get a sense of the health of an automatic transmission based on what has worn off it's 1,000's of parts previous to the pan's removal. The less debris we find, the brighter the transmission's future.
